Oil Pressure Sensor
FuelTech 0-150 PSI Oil Pressure Sensor Summary
An oil pressure sensor is not required for the ECU to operate, but it is highly recommended for monitoring engine health and ensuring safe operation. The stock oil system typically operates at pressures ranging from 30 to 80 PSI, depending on engine conditions. Adding an oil pressure sensor to this system is straightforward and provides critical real-time data for monitoring oil pressure. In this example, I used a FuelTech 0-150 PSI sensor, but any pressure sensor capable of handling oil is acceptable. Ensure the input is correctly configured in FT Manager.
FuelTech 0-150 PSI Oil Pressure Sensor
The FuelTech PS-150 Pressure Sensor (Part #5005100020-BLK) is designed for accurate and reliable pressure readings in the range of 0-150 PSI. It is typically used to monitor oil, fuel, or wastegate pressure, making it an essential component for performance-driven setups.
FuelTech PS-150 0-150 PSI Oil Pressure Sensor
Standard Pressure Sensor Connector
The FuelTech Oil Pressure Sensor 3-Pin Connector Kit ensures a secure and reliable connection for accurate data transmission to your engine management system. Below is the part number for the connector kit:
| Component | Part Number |
|---|---|
| Oil Pressure Sensor 3-Pin Connector Kit | 5005100023 |
FuelTech 3-Pin Connector Kit
Mounting the Pressure Sensor
To mount the PS-150 oil pressure sensor in place of the stock oil pressure switch, note that the PS-150 uses 1/8"-27 NPT threads, while the stock switch has 1/8" BSPT threads with 28 TPI and a slightly smaller major diameter (0.383" vs. 0.405"). Due to differences in thread angle (55° for BSPT vs. 60° for NPT) and pitch, these threads are incompatible, requiring an adapter. A 1/8 BSPT to 1/8" NPT female adapter, easily found on Amazon or eBay, will allow the PS-150 sensor to be securely installed in the same location as the oil pressure switch.
Wiring Diagram
The FuelTech PS-150 Oil Pressure Sensor uses a standard 3-pin connector with the following pinout: A - Ground, B - 5V, C - Signal. Wiring these sensors is straightforward; refer to the FuelTech manuals for additional details if needed. You can use any available white input. See the wiring diagram below for proper installation.
Wiring Diagram for FuelTech PS-150 Oil Pressure Sensor
Refer to the FuelTech documentation page for details on how the wiring diagram was created and to find the library of symbols used for this sensor.
FuelTech Manual
For detailed installation and configuration instructions, refer to the official FuelTech manual available at: FuelTech Support Page.
